BT-1660 Cordless Barcode Scanner

Cipherlab BT1600 Cordless Barcode Scanner Series

Smaller than your mobile phone, the 1600 series packs a lot of versatility in such a handy package. The 1600 series delivers thousands of scans and over a day of work using rechargeable Li-ion batteries. What's more, when used as a memory scanner, the 1600 series holds over 240 thousand scans. Able to read high-density 1D barcodes, and now with the capability of 2D barcode capture. The Bluetooth connectivity of the 1600 Series also enables instantaneous data transmission to a PDA or Android/IOS smartphone.

Cipherlab BT1662 Cordless Laser Bluetooth Barcode Scanner
(LiOn rechargeable batteries)		 $695 Add to Cart
Cipherlab BT1662 Cordless Laser Bluetooth Barcode Scanner
(LiOn rechargeable batteries)
WITH Plug In USB Bluetooth transponder for your Computer 		$795 Add to Cart
Cipherlab BT1663 Cordless Linear Imager Bluetooth Barcode Scanner
(LiOn rechargeable batteries)		 $395 Add to Cart
Cipherlab BT1663 Cordless Linear Imager Bluetooth Barcode Scanner
(LiOn rechargeable batteries)
WITH Plug In USB Bluetooth transponder for your Computer 		$495 Add to Cart
Cipherlab BT1664 2D Cordless Bluetooth Barcode Scanner
(LiOn rechargeable batteries)		 $995 Add to Cart
Cipherlab BT1664 2D Cordless Bluetooth Barcode Scanner
(LiOn rechargeable batteries)
WITH Plug In USB Bluetooth transponder for your Computer 		$1095 Add to Cart

Features & Benefits


Long Distance Cordless Communication
Built-in Bluetooth® for instant connections anywhere, anytime.

Advanced Memory Capabilities
Store up to 512k of scanned data in Batch mode.

High Speed Barcode Scanning
A quick 100 scans/second for fast, accurate workflow.

Clever Design
Lightweight, ergonomic design for repetitive use.

Long Distance Communications
Line of sight coverage up to 10 meters or 33 feet.

High Reliability and Long Battery Life
Lower power consumption with 30-hour to 40-hour work performance.

Plug-and-play, with USB cable
Easy to setup, scan one configuration barcode.

Downloads


BT-1600 Portable Barcode Scanner Brochure

BT-1600 Specifications

  BT-1662 BT-1663 BT-1664
RF Module Bluetooth® Class 2 (2.4 GHz) Version 2.1 +EDR
Coverage 20 m / 66 ft. line of sight
Scanner Type Laser scanner Linear imager scanner 2D imager scanner
Optical Sensor Laser 2500 pixels 752 x 480 pixels
Light Source Visible laser diode at 650 nm 625 ±5 nm Red LEDs (2x)
Resolution 4 mil 3 mil 3 mil - 1D barcode /
5 mil - 2D barcode
Depth of Field 2 to 42 cm /
0.8 to 16.5 in.		 2.4 to 38 cm /
0.9 to 15 in.		 Code 39 3 mil: 6.9 to 10.7 cm / 2.7 to 4.2 in.
Code 39 5 mil: 3.6 to 18.5 cm / 1.4 to 7.3 in.
UPCA 13 mil: 4.0 to 30.5 cm / 1.6 to 12 in.
PDF417 5 mil: 7.1 to 11.4 cm / 2.8 to 4.5 in.
PDF417 6.67 mil: 4.8 to 17.5 cm / 1.9 to 6.9 in.
Scanning Angle Pitch ± 65°
Skew ± 50°		 Pitch ±70°
Skew ±70°		 Pitch ± 60°
Skew ± 60°
PCS Minimum 30%
Scan rate 100 scans / second 200 scans / second 60 scans/ second
Barcodes supported Codabar, Code 32, Code 39, Trioptic Code 39,
Code 93, Code 128, Industrial 2 of 5,
Interleaved 2 of 5, ISBT-128,
Italian Pharmacodes, MSI Plessey,
Bookland EAN, GS1-DataBar, GS1 DataBar-14,
GS1 DataBar Limited, GS1 DataBar Expanded,
UPC-A, UPC-E, UPC-E1, EAN-8, EAN-13		 Codabar, Code 39, Code 93, Code 128,
GS1 DataBar(RSS), Industrial 2 of 5,
Italian and French Pharmacodes,
Interleave 2 of 5, Matrix 2 of 5, MSI, Plessey,
Telepen, UPC/EAN/GS1-128, and mor		 1D: All major codes*1
2D: PDF417, MicroPDF417, Composite, RSS,
TLC-39, Datamatrix, QR code,
Micro QR code, Aztec, MaxiCode
Postal Codes: US PostNet, US Planet,
UK Postal, Australian Postal,
Japan Postal Dutch Postal (KIX)
Programmable features Data editing, interface selection, symbology configuration
Language support US and UK English, French, Italian, Belgian, Norwegian, Swedish, Spanish, Portuguese, German, Swiss German, Japanese, Turkish, Hungarian, and Danish
Weight
(including battery)		 100 g / 3.53 oz 106 g / 3.7 oz.
Size 11.3 x 4.5 x 3.0 cm / 4.4 x 1.8 x 1.2 in.
Color Black
Button Power and scan keys
Memory 4MB
Working Hours 35 hours based on
1 scan / 5 seconds		 40 hours based on
1 scan / 5 seconds		 24 hours based on
1 scan / 5 seconds
Power Supply Li-ion 3.7V, 850 mAh
Power consumption
Standby / Operating		 20 mA / 100 mA
@ 3.7 V		 20 mA / 224 mA
@ 3.7V		 20 mA / 250 mA
@ 3.7 V
Temperature Operating : 0 °C to 50°C / 32°F to 122°F
Storage : -20°C to 60°C / -4°F to 140°F( w/o battery )
Humidity
(non-condensing)		 Operating : 10% to 90% / Storage: 5% to 95%
Impact resistance 1.5 m / 4.9 ft. multiple drops onto concrete
Ingress protection IP42
Electrostatic discharge ± 8 kV contact / ± 15 kV air
EMC regulation BSMI, CE, C-tick, FCC, NCC, IC, TELEC, SRMC BSMI, CE, FCC, NCC, TELEC BSMI, CE, C-tick, FCC, NCC, IC, TELEC, SRMC
Configuration Setup option includes Windows®- based ScanMaster software
Accesories 3610 Bluetooth® transponder, Micro USB cable,
battery charger, protective cover
Warranty 1 Year
